LIOUY HSING Horizontal Lathe
Year of production：2017Controller：FANUC-0iTF
Specifications：
X/Z travel：165/540mm
Rapid Traverse：20/ 24m/min
Tool Capacity：8 tools
Max Swing Diameter：400mm
Max Machining Diameter：330mm
Max Machining Length：540mm
Bar Capacity Diameter：52mm
Tailstock Slide Travel：540mm
Tailstock Quill Taper：MT#4
Tailstock Quill Diameter：75mm
Spindle Rigid Tapping
Spindle Torque Detection & Multi-point Positioning
Accessories：
(1) Spindle Speed 3500rpm
(2) 10"x3 jaw Hollow Hydraulic Chuck
(3) USB & CF Card Transmission Interface
(4) Oil-Water Separator
(5) Chip Conveyor + 1 Chip Cart
★ Bar Feeder Included For Free★
